Lynx Technik yellobrik OSP 1812 Passive Optical Splitter / Combiner

The OSP 1812 M is a compact passive optical splitter/combiner designed to split or combine fiber optic signals efficiently. With one input at 100% power, it provides two outputs: one at 90% power and a second at 10% power, making it ideal for monitoring applications. As a passive device, it requires no external power, offering flexibility in various installation scenarios. The module can function as a standalone unit or be mounted into the yellobrik RFR 1018 19” rack frame for organized rack installations.

Key Features

• Optical splitter/combiner functionality
• Passive operation (no power required)
• LC optical connections
• Optional ½ RU 19” rack frame compatibility

Technical Specifications

Optical Splitter Configuration

• One input (100%) and two outputs:
  • Output 1: 90% power
  • Output 2: 10% power (typically used as a monitoring output)

Optical Connections

• LC/PC connectors
• Single-mode fiber compatibility

Physical Characteristics

• Compact design suitable for standalone use or rack-mounted installation
• Compatible with LYNX Technik's RFR 1018 0.5RU Rack Frame for passive fiber modules
