Blackmagic Design UltraStudio HD Mini video capturing device
SKU
BDLKULSDMINHD
£498.54
£415.45
In stock
Low stock — limited availability.
BNC, HDMI, Y,B-Y,R-Y, 1080p60
| Product colour | Black |
|---|---|
| SKU | BDLKULSDMINHD |
| EAN | 09338716004809 |
| Manufacturer | Blackmagic Design |
| Availability | Y |
UltraStudio HD Mini features professional broadcast quality connections that include 3G-SDI, analog YUV and composite NTSC/PAL video inputs, along with a reference input. There are also two ¼” audio connections for analog audio input that work with balanced and HiFi sources. In addition, UltraStudio HD Mini can remote control professional broadcast decks using the built in RS-422 connection. For output, you get dual link 3G-SDI with fill and key, and an HDMI connection for monitoring video with a big screen television!
| Performance | |
|---|---|
| Internal | No |
| Product colour | Black |
| Technical details | |
| Internal | No |
| Product colour | Black |
| Video | |
| Analog signal format system | NTSC, PAL |
| Video capturing speed (PAL) | 50 fps |
| Video capturing speed (NTSC) | 59.94 fps |
| Supported video modes | 525i, 625i, 720p, 1080i, 1080p |
| Maximum frame rate | 60 fps |
| Ports & interfaces | |
|---|---|
| Number of HDMI outputs | 1 |
| Component video (YPbPr/YCbCr) in | 1 |
| Audio (L/R) in | 1 |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 40 °C |
| Storage temperature (T-T) | -20 - 45 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions | |
| Width | 140 mm |
| Depth | 170 mm |
| Height | 44 mm |
| Weight | 610 g |
| Packaging content | |
| Quantity | 1 |
